Stage Lighting Server / ZM-GC500-19

Product Overview

This core lighting control device is designed for stage performances and large-scale events. It centrally manages lighting equipment (LEDs, lasers, moving heads, etc.) to deliver precise timing control, synchronized effects, and automated operations. Built on an embedded Linux system, it supports Art-net/sACN protocol consoles or control software such as MA2, Madrix, and Arena, with solid-state drive storage.

Product Features

1、Works with standard Art-NET controllers; supports up to 512 zones. Features scheduled playback (holidays), GPS time synchronization, and wireless sync across multiple devices.
2、Some IC controllers for DMX fixtures include built-in address writing capabilities. They support standard DMX512 and RDM-compatible fixtures.
3、Centralized Control Mode: Connects to the master control via fiber optic or 4G for remote management and control.
4、Standalone mode with built-in web interface for programming and controlling lighting, audio, and high-voltage systems. Supports standalone operation of lighting scenes, scheduling, and light shows.

Interface
	Ethernet port	2-port 10/100/1000M adaptive Ethernet RJ45 port
	Industrial Serial Port	1 DB9 ports, defaulting to RS85 levels and configurable to TTL or RS-232 levels
Structure Parameters
	CPU	Cortex-A55, up to 2.0G.Hz
	DDR	LPDDR4 2GB(4G\|8G (optional)
	Storage	16/32/64: Default 3 2GB
	Operating System	LINUX
	System Architecture	ARM
Power Consumption
	Communication current	<360mA (12V)
	Communication Status	Under 4W
Power
	Operating Voltage	AC 10-220V
	Power Consumption	24W
Environment Requirements
	Operating Temperature Range	20°C--70°C
	Operating Humidity Range	95% No Condensation
Security
	MSATA	Standard 32GSSD drive
	Firewall	Create a buffer between the unsafe system and the secure system.
	Link Detection	Maintain wireless connectivity via ICMP probing and application-layer heartbeats, with automatic reconnection on disconnection to ensure devices remain "permanently online."
Network
	4G/5G	Supports TD-LTE 2600/2300MHz, FDD-LTE 2600/2100/1800/900/800MHz, TD-SCDMA, WCDMA, EVDO, CDMA, and GPRS.
	VPN	Support
	Wi-Fi	Optional
Features
	NTPD	Supports network time synchronization/protocol
	RTC Clock	Supports local hardware clock
	DHCP	Supports DHCP service
Application Business
	WEB	Supports web services with configurable standalone or cloud control modes. Enables upload of position maps, program creation, and playlist management. Features real-time playback preview and Art-Net output monitoring. Supports Art-Net data recording and playback. Includes one-click control, strategy-based control, address testing, and fixture addressing functions.
	Wi-Fi	Supports AP mode for device connectivity; also allows access to web services via Wi-Fi.
	ARTNET	Supports Art-Net input; controls playback speed and switches playback effects
	Load Capacity	512 domains, each with configurable data length up to 1440 bytes
	Decoding capability	Best supports 1920x1080 resolution decoding;
	MODBUS	Optional
